Self Study Program 245 – AUDI RS 4

Self Study Program 245 – AUDI RS 4 PDF free online

This self-study programme describes the special features of the Audi RS4 only. Basic information is provided in SSP 198, which describes the Audi S4 in detail.

With the Audi RS4, quattro GmbH, a fully owned subsidiary of Audi AG, has independently designed its first complete vehicle, which it has developed in cooperation with Audi AG.

The RS4, which like its predecessor, the RS2, is produced exclusively as an Avant, is the absolute top-of-the-range model in the A4 class.

Based on the Audi S4, a high-performance vehicle has been created which is designed for an uncompromising sports appeal both in technical and visual terms.

The Audi RS4 impresses by virtue of it superior performance, and radiates individuality and exclusiveness thanks to the well co-ordinated high-quality materials in the vehicle interior.

CONTENTS

  • Body
    • The Audi RS4
    • Side sills
    • Front end
    • Rear spoiler
  • Brief summary
  • Engine and gearbox

    • Engine – RS4
    • Crankcase/crank assembly
    • Cylinder head
    • Piston/conrod
    • Engine cooling system
    • Injection system
    • Fuel system
    • Secondary air system
    • Engine management
    • Air cleaner with additional air valve
    • Intake air change-over valve
    • Charge air cooler
    • Gearbox
  • Running gear
    • Front axle
    • Rear axle
  • Air conditioner
  • Technical data

The self-study programme will provide you with information on design and functions.

The self-study programme is not intended as a workshop manual.
For maintenance and repair operations it is essential that you refer to the current technical literature.

Language: English
Format: PDF
Pages: 39
