Self Study Program 666 – Audi A8 (type 4N) Infotainment and Audi connect

VAG SSP 666. With its  MIB2+  generation of the modular infotainment matrix, the Audi A8 (type 4N) is a fundamental revolution for Audi models regarding information and entertainment in the vehicle. It represents a new milestone for Audi’s entire product range.

Customers can choose between two MMI versions on the Audi A8: the MMI radio plus and the MMI navigation plus. The chosen system can be adapted to the customer’s needs with optional equipment.

The significantly improved performance of the system, the introduction of new functions and hardware, the innovative operating concept and the further integration of the Internet in both convenience and safety/security-related applications make travelling in the Audi A8 an exceptional experience. Thanks to the modular structure of the control unit 1 for information electronics J794, this experience will continue to take on new dimensions.
