Self Study Program 647 – Audi A4 (type 8W) Infotainment and Audi connect

AUDI SSP

VAG SSP 647. As you would expect from Audi, the infotainment system in the Audi A4 offers a perfect combination of driver orientation, networking and intuitive operation.

CONTENTS

Introduction
- Overview of versions
MIB Scale
- Directory
MMI versions
- MMI Radio plus
- MMI radio plus with Connectivity Package
- MMI Navigation
- MMI Navigation plus
Sound
- Basic sound system (8RM)
- Audi sound system (9VD)
- Bang & Olufsen Sound System with 3D sound (9VS)
Aerials
- Aerials overview
- Telephone aerials
- Aerial versions
MMI display
- MMI display
Control panel
- Multimedia system control panel E380
- Button combinations for service personnel
Audi phone box
- Audi phone box
- Connection of 2 mobile phones
- Wireless charging (country-dependent)
Networking
- Networking
- Topology
Audi connect
- Audi connect (depending on market)
- Audi connect infotainment services (depending on market)
- Audi connect vehicle-specific services (depending on market)
- The hardware

The Self Study Programme teaches a basic knowledge of the design and mode of operation of new models, new automotive components or new technologies.
It is not a Repair Manual! Figures are given for explanatory purposes only and refer to the data valid at the time of preparation of the SSP. This content is not updated.
For further information on maintenance and repair work, always refer to the current technical literature.

Language: English
Format: PDF
Pages: 40

Self Study Program 647 – Audi A4 (type 8W) Infotainment and Audi connect PDF free online
