Self Study Program 94 – Diagnosis of the automatic gearboxes 0AM and 02E

VAG SSP 94. This workshop teaching aid complements the previously published self-study brochures:

– SSP No. 56, six-speed automatic transmission 02E
– SSP No. 75, seven-speed automatic transmission 0AM

This highly specialized 40-page PDF file contains the official VAG Self-Study Program 94 (SSP 94), a diagnostic manual focused entirely on troubleshooting the 7-speed 0AM (dry clutch) and the 6-speed 02E (wet clutch) Direct Shift Gearboxes. While earlier Self-Study Programs (like SSP 56 and SSP 75) explain the physical design and mechanical function of these transmissions, SSP 94 serves as a supplementary workshop teaching aid explicitly dedicated to fault finding and rectification. It is an absolute must-have for VAG diagnostic technicians, Mechatronics rebuilders, and advanced DIYers dealing with drivability issues or flashing PRNDS displays on DSG-equipped vehicles.

Please note: This manual assumes the reader already understands the mechanical architecture of the 0AM and 02E. It focuses on diagnostic procedures, common failure points, and software adaptation rather than step-by-step mechanical teardowns.

This detailed diagnostic training manual covers the following key troubleshooting topics:

• Common Faults and Root Causes: A breakdown of frequent problems encountered when operating vehicles with the 02E or 0AM gearboxes. It helps technicians trace physical symptoms (like shuddering, slipping, or harsh engagements) to their specific mechanical or electronic root causes within the dual clutches or the Mechatronics unit.
• Diagnostic Procedures (VAS Interface): Detailed instructions on how to correctly implement diagnostics using the factory VAS testing units. It explains how to interpret specific fault codes and live measuring blocks to accurately pinpoint failing components.
• Mechatronics Replacement and Coding: Critical guidance for replacing the electronic/hydraulic control unit. It outlines the necessity of saving the original coding via an Auto-Scan and the procedure for entering that coding into a new or remanufactured Mechatronics module.
• Basic Settings and Calibration: An essential overview of the precise procedures required to recalibrate the transmission tolerances after a repair. This includes the crucial “Defined Test Drive” protocol necessary to ensure the clutches adapt properly to the new tolerances.
• Technical Modifications: A summary of important updates and modifications made to both the 0AM and 02E platforms since their initial release, helping technicians identify revised parts.

Whether you are trying to properly code a replacement Mechatronics unit, diagnose a clutch shudder on a DQ200 (0AM), or need to know the correct procedure for the “Defined Test Drive” to adapt a new clutch pack, SSP 94 is the definitive troubleshooting resource.

CONTENTS

• 1. Introduction
• 2. Basic comparison of the gearboxes 0AM (DQ 200) and 02E (DQ 250)
• 3. Seven-speed automatic transmission 0AM
  • 3.1 Changes in the mechanical part of the gearbox 0AM
    • 3.1.1 Design adjustments to the clutch as of 01.06.2011 (PKO2 package)
  • 3.2 Diagnosis
    • 3.2.1 Introduction
    • 3.2.2 Measured value blocks
    • 3.2.3 Most common faults and their rectification
    • 3.2.4 Diagram of the recommended procedure when repairing the seven-speed gearbox 0AM
• 4. Six-speed gearbox 02E
  • 4.1. Diagnosis
    • 4.1.1 Introduction
    • 4.1.2 Measured value blocks
    • 4.1.3 Most common faults and their rectification
    • 4.1.4 Diagram of the recommended procedure for repairing the six-speed gearbox 02E
• 5. Technical question concerning the repair of the gearboxes 0AM and 02E and the documents thereto

Language: English
Format: PDF
Pages: 40

Self Study Program 94 – Diagnosis of the automatic gearboxes 0AM and 02E PDF free online
