The CAN bus system in a car interlinks the control units to form a network.
This produces new functions in the car and in diagnostics which span across control units.
SSP 186 “The CAN Databus” gave an initial overview of the technology. SSP 238 will now
describe the basic functions of the current CAN Bus system.

SSP 238:
Deals with basic functions of the current CAN system, e.g. the data exchange process

SSP 269:
Deals with special bus systems such as the Drive Train CAN bus and the Convenience CAN bus as used by VOLKSWAGEN and AUDI.
