VW 6-speed Automatic Transmission 09G Repair Manual (Edition 07.2015 D3E8001EAAC)

The VW 6-speed Automatic Transmission 09G Repair Manual (Edition 07.2015 D3E8001EAAC) is a comprehensive guide to repairing and maintaining the 09G automatic transmission of your Volkswagen vehicle. It covers all aspects of the repair process, from basic maintenance to more complex repairs. It also provides useful advice on how to keep your transmission in tip-top condition. With this manual, you can ensure that your VW 6-speed Automatic Transmission 09G stays in perfect condition and runs like new.

CONTENTS

  • General, Technical Data
    • General Repair Information
    • Torque Converter
    • ATF
    • Transmission Control Module J217 with Fuzzy Logic
    • Vehicle Control Modules
    • Information on the “Transmission 09G”
    • Tools
    • Transmission
    • Seals, Gaskets and Oil
    • Bolts and Nuts
    • Electrical Components
    • Guided Fault Finding, OBD and Test Instruments
    • Safety Precautions
    • Transmission Identification
    • Identification on Transmission
    • Capacities
    • Planetary Gear and Final Drive
    • Engine Codes – Engine Allocation
    • Special Tools
  • Torque Converter
    • Overview – Torque Converter
    • Torque Converter, Removing and Installing
    • Torque Converter, Checking
    • Torque Converter, Discharging
    • Torque Converter Seal, Removing and Installing
    • Special Tools
  • Controls, Housing
    • »Tester«, Connecting
    • Electrical and Electronic Components and Component Locations
    • Multifunction Transmission Range Switch F125
    • Multifunction Transmission Range Switch F125 , Removing
    • Multifunction Transmission Range Switch F125 , Installing
    • Multifunction Transmission Range Switch F125 , Adjusting
    • Selector Mechanism through 02/2009
    • Overview – Selector Mechanism through 02/2009
    • Shift Mechanism with Selector Lever, Removing and Installing, through 02/2009
    • Selector Lever Cable, Removing and Installing, through 02/2009
    • Selector Lever Cable, Checking
    • Selector Lever Cable, Adjusting
    • Selector Lever, Emergency Release
    • Selector Lever Handle, Removing and Installing
    • Button in Handle, Moving into Installation Position
    • Selector Mechanism, Checking
    • Selector Mechanism from 03/2009
    • Overview – Selector Mechanism from 03/2009
    • Selector Mechanism, Removing and Installing, Vehicles from 03/2009
    • Transmission, Removing and Installing, Jetta from 2005, Golf Wagon from 2007, Jetta Wagon from 2008
    • Transmission, Removing, Vehicles with 2.0L – 85kW and 2.0L – 110kW Engines
    • Transmission, Installing, Vehicles with 2.0L – 85kW and 2.0L – 110kW Engines
    • Transmission, Removing, Vehicles with 2.5L – 110 kW and 2.5L -125 kW Engines
    • Transmission, Installing, Vehicles with 2.5L – 110 kW and 2.5L – 125 kW Engines
    • Tightening Specifications, Transmission to Engine
    • Transmission, Removing and Installing, Jetta from MY 2011
    • Transmission, Removing, Jetta MY 2011 1.6L 77 kW
    • Transmission, Removing, Jetta MY 2011, 2.0L 85 kW
    • Transmission, Removing, Jetta MY 2011, 2.5L 125 kW
    • Transmission, Installing, Jetta MY 2011
    • Tightening Specifications, Transmission to Engine
    • Transmission, Transporting
    • Transmission, Securing in Engine/Transmission Holder
    • ATF Cooler
    • Overview – ATF Cooler Round Version
    • Overview – ATF Cooler Rectangular Version
    • ATF Level, Checking and Filling
    • ATF Level, Checking
    • ATF, Filling
    • ATF, Draining and Filling
    • Special Tools
  • Gears, Hydraulic Controls
    • Selector Shaft Seal, Replacing
    • Transmission Fluid Pan
    • Transmission Fluid Pan, Removing and Installing
    • ATF Screen
    • ATF Screen, Removing and Installing
    • Valve Body
    • Overview – Valve Body
    • Valve Body, Removing and Installing
    • Solenoid Valve Wiring Harness (14-Pin Connector), Removing and Installing
    • Sensor Wiring Harness (8-Pin Connector), Removing and Installing
    • Transmission Input Speed Sensor G182 , Removing and Installing
    • Transmission Output Speed Sensor G195 , Removing and Installing
    • Special Tools
  • Final Drive, Differential
    • Flange Shaft Seals, Replacing
    • Component Location Overview – Seals
    • Left Flange Shaft Seal, Replacing
    • Right Flange Shaft Seal, Replacing
    • Special Tools
    • Revision History

Language: English
Format: PDF
Pages: 167

VW 6-speed Automatic Transmission 09G Repair Manual (Edition 07.2015 D3E8001EAAC) PDF free online
