Toyota Yaris Body Collision Damage Repair

This repair manual has been prepared to provide essential information on body panel repair methods (including cutting and welding operations, but excluding painting) for the TOYOTA YARIS. Applicable models: KSP90 series, NCP90, 91 series

This manual consists of body repair methods, exploded diagrams and illustrations of the body components and other information relating to body panel replacement such as handling precautions, etc. However, it should be noted that the front fenders of, this TOYOTA model are bolted on and require no welding.

When repairing, don’t cut and join areas that are not shown in this manual. Only work on the specified contents to maintain body strength.

Body construction will sometimes differ depending on specifications and country of destination. Therefore, please keep in mind that the information contained herein is based on vehicles for general destinations.

For the repair procedures and specifications other than collision damaged body components of the TOYOTA YARIS refer to the repair manuals. All information contained in this manual is the most up-to-date at the time of publication. However, specifications and procedures are subject to change without prior notice.

Language: English
Format: PDF
Pages: 339

Toyota Yaris Body Collision Damage Repair
