Toyota Hilux fault codes

Toyota Hilux fault codes list

Fault codes of petrol engines (Toyota)

The self-diagnosis codes are read by the number of flashes of the indicator “CHECK ENGINE” with the closed terminals “TE1” – “E1” of the DLC1 connector under the hood or “TC” – “CG” of the DLC3 connector under the dashboard and the ignition on. The DLC2 connector is also closed in it “TE1” – “E1”.
If there is no malfunction, the indicator flashes at 0.25 second.
If there is a malfunction, the indicator gives the beginning of the tens in 0.5 seconds, then a pause of 1.5 seconds and a unit with a pause of 0.5 seconds.
In the presence of two or more codes, a pause between them is 2.5 seconds.
After the output of all codes, there is a pause of 4.5 seconds, and then the codes are repeated.

12 – Crankshaft Position Sensor (P0335)
13 – Crankshaft Position Sensor (P0335, P1335)
14 – Ignition system, coil No. 1 (P1300) and No. 4 (P1315)
15 – Ignition system, coil No. 2 (P1305) and No. 3 (P1310)
16 – Automatic transmission control system
18 – VVT-i system – phases (P1346)
19 – Accelerator pedal position sensor (P1120)
19 – Accelerator pedal position sensor (P1121)
21 – Oxygen sensor (P0135)
22 – Coolant temperature sensor (P0115)
24 – Intake air temperature sensor (P0110)
25 – Oxygen sensor – poor mix signal (P0171)
26 – Rich mixture (P0172)
27 – Oxygen sensor # 2
31 – Absolute pressure sensor (P0105, P0106)
33 – ISCV valve (P0505)
34 – Turbocharging system
35 – Turbocharger pressure sensor
36 – CPS sensor (P1105)
39 – VVT-i system (P1656)
41 – Throttle Position Sensor (P0120, P0121)
42 – Vehicle speed sensor (P0500)
43 – Starter signal
47 – Additional throttle position sensor
49 – Fuel pressure sensor (D-4) (P0190, P0191)
51 – Status of switches
52 – Knock sensor (P0325)
53 – Detonation signal
55 – Knock Sensor No.2
58 – Drive SCV (D-4) (P1415, P1416, P1653)
59 – Signal VVT-i (P1349)
71 – EGR system (P0401, P0403)
75 – Pressure Sensor GUR (P0550)
78 – injection pump (D-4)
89 – Drive ETCS (P1125, P1126, P1127, P1128, P1129, P1633)
92 – Cold start nozzle (D-4) (P1210)
97 – Nozzles (D-4) (P1215)

Diesel engine trouble codes (Toyota)

12 – Crankshaft Position Sensor
13 – Speed ​​sensor
14 – The valve of adjustment of a corner of an advancing of injection
15 – Throttle servo
17 – Control unit signal
18 – Electromagnetic bypass valve
19 – Accelerator Pedal Position Sensor
22 – The gauge of temperature of a cooling liquid
24 – Intake Air Temperature Sensor
32 – Correction resistors
33 – Throttle actuator
35 – Charge pressure sensor
39 – Fuel temperature sensor
42 – Vehicle speed sensor
47 – Throttle Position Sensor
89 – ECU (IC)
96 – EGR Valve Position Sensor

Transmission fault codes of Toyota Hilux

The self-test codes are read by the number of flashes of the “O / D OFF” indicator when the terminals “D11” under the bonnet or “TC” – “CG” of the DLC3 connector under the dashboard are closed and the ignition on (terminals up gear – “O / D OFF” is not lit).

11 – Norm
37 – Input speed sensor for automatic transmission (P1705)
38 – The gauge of temperature of a working liquid АКПП
42 – Speed ​​sensor (or output speed sensor) (P0500)
44 – Speed ​​sensor (or rear output speed sensor)
46 – Pressure accumulator pressure control solenoid (P1765)
61 – Speed ​​sensor (or front output speed sensor)
62 – Solenoid No. 1 (P0753)
63 – Solenoid No. 2 (P0758)
64 – Torque converter lock solenoid (P0773)
67 – Input speed sensor for automatic transmission
68 – Torque converter clutch control solenoid
73 – Interaxle differential lock solenoid

Fault codes ABS (Toyota Hilux)

Reading codes (models with DLC1 connector)

– Switch on the ignition.
– Connect the “TC” and “E1” terminals of the DLC1 connector.
– Remove the jumper from the “WA” and “WB” terminals of the DLC1 connector.
– After 4 seconds, read the code by the number of indicator flashes.
– Remove the jumper from the terminals “TC” and “E1”.
– Set the jumper on the “WA” and “WB” terminals.

Resetting codes (models with DLC1 connector)

– Switch on the ignition.
– Connect the “TC” and “E1” terminals of the DLC1 connector (the car is stationary).
– Depress the brake pedal eight or more times in the interval of three seconds.
– The indicator should output the normal code (flashing 2 times per second).
– Switch off the ignition.
– Remove the jumper from the terminals “TC” and “E1”.
– Check that the ABS indicator goes out.

Reading codes (models with DLC3 connector)

– Connect the “TC” and “CG” terminals of the DLC3 connector.
– Switch on the ignition.
– After 4 seconds, read the code by the number of indicator flashes.
– Remove the jumper from the terminals “TC” and “CG”.

Reset codes (models with DLC3 connector)

– Connect the “TC” and “CG” terminals of the DLC3 connector.
– Switch on the ignition.
– Depress the brake pedal eight or more times in the interval of three seconds.
– The indicator should output the normal code (flashing 2 times per second).
– Remove the jumper from the terminals “TC” and “CG”.

11 Open circuit of solenoid valve relay
12 Short circuit in the circuit of the electric motor relay
13 Open circuit in the electric pump relay circuit
14 Short circuit in the electric pump relay circuit
21 Open or short circuit in front right wheel emf valve
22 Open or short circuit in the front left-hand wheel
23 Open or short circuit in the rear right (left) wheel
24 Open or short circuit in the left rear left (right) wheel
31 Front right wheel speed sensor fault
32 Front left wheel speed sensor fault
33 Rear right wheel speed sensor fault
34 Rear left wheel speed sensor fault
35 Contact with foreign material between the rotor and the front right ABS sensor
36 Contact with foreign material between the rotor and front left ABS sensor
38 Foreign material entering between rotor and ABS sensor of rear right wheel
39 Foreign material entering between rotor and left rear wheel ABS sensor
41 Battery voltage too high or too low
43 Malfunction in the deceleration sensor circuit
44 Open or short circuit in the deceleration sensor circuit
49 Open circuit in the brake light switch circuit
51 Short-circuit or open circuit of the electric pump power supply
71 Front left wheel speed sensor low
72 Low level signal from the front left wheel speed sensor
73 Signal level from the rear right wheel speed sensor
74 Signal from rear left wheel speed sensor low
75 Wrong change in the signal from the front right-hand wheel speed sensor
76 Incorrect change of the signal from the sensor of the speed of the front left wheel
77 Incorrect change in the signal from the rear right wheel speed sensor
78 Incorrect change in the signal from the rear left wheel speed sensor
79 Malfunction of the deceleration sensor
98 – The vacuum sensor in the vacuum brake booster (C1200

SRS Fault Codes Toyota Hilux

The self-test codes are read out in the same way as the others, in terms of the number of flashes of the “SRS” indicator when the terminals “TC” – “E1” of the DLC1 connector under the hood or “TC” – “CG” of the DLC3 connector under the dashboard are switched on and the ignition is switched on.

Erasing codes must occur when the ignition is switched off. If the codes are saved, you need to perform the cleaning procedure:
– connect two wires to the terminals “TC” and “AB”
– switch on the ignition and wait at least 6 seconds
– alternately, once per second, connect the terminals “TC” and “AB” (the pause between the closures is less than 0.2 seconds)
– after the third closing of the output “TC” the indicator should blink at a high frequency – the codes are erased.

11 – Driver’s ignitor PB (short to ground)
12 – Driver’s Igniter (short to power)
13 – Driver’s Igniter (short circuit in the circuit)
14 – Driver’s Igniter (break in the chain)
15 – Front right SRS sensor (short circuit or open circuit)
15 – Front right SRS sensor (short to ground or power)
16 – Front left SRS sensor (short circuit or open circuit)
16 – Front left SRS sensor (short to ground or power)
31 – Malfunction of the SRS control unit
51 – Passenger’s igniter PB (short to ground)
52 – Passenger’s igniter PB (short to power)
53 – Passenger’s igniter PB (short circuit in the circuit)
54 – Passenger Igniter (break in the chain)
61 – Driver belt pretensioner ignition (short to ground)
62 – Driver’s belt pretensioner (short to power)
63 – Driver’s belt pretensioner (short circuit in chain)
64 – Driver belt pretensioner ignition (open circuit)
71 – Passenger belt pre-tensioner igniter (short to ground)
72 – Passenger belt pre-tensioner igniter (short to power)
73 – Passenger belt pretensioner ignition (short circuit in the chain)
74 – Passenger belt pre-tensioner igniter (break in chain)

4WS fault codes (Toyota)

The self-diagnosis codes are read by the number of flashes of the “4WS” indicator when the terminals “TC” – “E1” of the DLC1 connector under the hood are closed and the ignition is switched on.

1 Electronic control unit 4WS
12 Main Steering Motor Malfunction
13 Malfunction of the steering control actuator
21 Short circuit in the main motor system
22 Main circuit break in the main motor system
23 Main motor lock
24 Malfunction of the main motor
31 Break in the reverse motor system
32 Malfunction of the reverse motor
41 Front left wheel speed sensor fault
42 4WS System Sensor Malfunction
43 Incorrect operation of the 4WS sensor

P/S system fault codes of Toyota Hilux

To check, open the TC and CG terminals of the DLC 3 connector. And read the trouble codes according to the number of P / S indicator flashes.
To remove errors, plug out the TS and CG pins of the DLC 3. Connect the ignition and within 8 seconds.
At least 4 times close and open the contact between the terminals TS and CG.

11 Torque sensor (1)
12 Torque sensor (2)
13 Torque sensor (3)
14 Moment Sensor Power Circuit Malfunction
15 Calibration of the DM zero has not been performed
16 calibration of the DM zero point is not completed
21 motor malfunction (current higher than permissible)
23 motor malfunction (current deflection)
24 Motor malfunction (voltage deviation)
31 failure of the ECM control module
32 failure of the ESD
33 Temperature sensor failure of the ESD
41 speed sensor
42 speed sensor
44 crankshaft rotation sensor
45 crankshaft rotation sensor
51 power supply circuit fault
52 supply voltage of the ESD
54 Power Supply Relay Circuit Malfunction
55 motor relay relay malfunction
