Toyota 1hd 1hz 1pz-t Engine Service Repair Manual (RM172E)

This repair manual has been prepared to provide information covering general service repairs for the 1 PZ, 1 HZ and 1HD-T engines equipped on the TOYOTA LAND CRUISER and COASTER.

Applicable models:

  • PZJ70, 73, 75 series
  • HZJ70, 73, 75, 80 series
  • HDJ80 series
  • HZB30 series
  • HDB30 series

Please note that the publications below have also been prepared as relevant service manuals for the components and system in this engine.

All information in this manual is based on the latest product information at the time of publication. However, specifications and procedures are subject to change without notice.

This manual does not include all the necessary items about repair and service, this manual is made for the purpose of the use for the persons who have special techniques and certifications. In the cases that non-specialized or uncertified technicians perform repair or service only using this manual or without proper equipment or tool, that may cause severe injury to you or other people around and also cause damage to your customer’s vehicle.

In order to prevent dangerous operation and damages to your customer’s vehicle, be sure to follow the instruction shown below.

CONTENTS

  • INTRODUCTION
  • ENGINE MECHANICAL
  • TURBOCHARGER SYSTEM
  • FUEL SYSTEM
  • COOLING SYSTEM
  • LUBRICATION SYSTEM
  • STARTING SYSTEM
  • CHARGING SYSTEM
  • SERVICE SPECIFICATIONS
  • STANDARD BOLT TORQUE SPECIFICATIONS
  • SST AND SSM

Language: English
Format: PDF
Pages: 348

Toyota 1hd 1hz 1pz-t Engine Service Repair Manual (RM172E) PDF free online
