The turbocharged 2.0L 4V chain-driven AVS engine (CAEB) described in this Self-Study Program is a development of the 1.8L chain-driven engine (EA 888 family) introduced
in Europe in 2006. The 1.8L engine, known as the Stage 0 engine, was the basis for the chain-driven 2.0L 4 cylinder engine (CCTA/CBFA) introduced in North America during
the 2008 model year.

This EA 888 family of engines is replacing the belt-driven camshaft engines within the Volkswagen Group world wide.

The 2.0L 4V chain-driven AVS engine is a further development of the earlier CCTA/CBFA engine. The cylinder block, crankshaft assembly and pistons of the CCTA/CFBA engine are similar to those of the CAEB engine. However, major changes to the cylinder head and
the addition of the Audi Valve Lift System (AVS) to the exhaust camshaft of the CAEB distinguishes this engine from the CCTA/CBFA engines.

Also included in this Self-Study Program is a description of changes needed to make a non-AVS 2.0L 4V chaindriven engine compliant with SULEV emission standards.

To see a brief description of the development history and a specification comparison of the EA 888 engines, please see the Appendix at the end of this book.

CONTENTS

  • Introduction
  • Engine Mechanicals
  • Oil Circulation System
  • SULEV 2.0L TFSI Engine
  • Service
  • EA 888 Engine Development
  • Knowledge Assessment

The Self-Study Program provides introductory information regarding the design and function of new models, automotive components or technologies.
The Self-Study Program is not a Repair Manual!
All values given are intended as a guideline only and refer to the software version valid at the time of publication of the SSP.
For maintenance and repair work, always refer to the current technical literature.

Language: English
Format: PDF
Pages: 56
