Self Study Program 871503 – The 2006 Passat Electrical System

Self Study Program 871503 – The 2006 Passat Electrical System PDF free online

This program also describes the new control modules, the networking of various body electrical systems, and the various CAN-bus systems.

The 2006 Passat makes extensive use of control modules and networking using multiple Controller Area Network (CAN) buses. Signals are transmitted digitally from one control module to another on each CAN-bus, eliminating the need for a separate wire for each signal. The use of CAN-bus communication for controls and accessories reduces the wires needed in the vehicle.

CONTENTS

  • Introduction
    • Course Introduction, Electrical System Fuses and Relays, Electric Box, Relay Holder and Fuse Boxes, Communication Network
  • Data Bus System
    • Drivetrain CAN-Bus Control Modules, Comfort CAN-Bus Control Modules, Infotainment, Instrument Clusterand Diagnosis CAN-Bus Control Modules, Sub-Bus Systems, Electric Parking Brake CAN-Bus Systems, Adaptive Front Lighting System CAN-Bus, Serial Data Bus
  • Electrical System
    • Vehicle Electrical System Control Module J519, Exterior Lighting, Light Switch, Exterior Lighting Circuit Diagram, Automatic Headlights, Vehicle Lighting, Data Bus On Board Diagnostic Interface J533, Instrument Cluster Control Module J285, Display Unit Versions, Warning Lights in the Instrument Cluster, Comfort System Central Control Module J393, Central Locking System, Vehicle Immobilizer IV, Components ofthe Vehicle Immobilizer, Control Modules Replacement, Start/Stop Operation, Electronic Steering Column Lock Control Module J764, System Diagram
  • Comfort and Safety Electronic System
    • Adaptive Front Lighting System, Personalization, Accessing Menu Options, Park Distance Control

This Self-Study Program covers the electrical system of the 2006 Passat. This Self-Study Program is not a Repair Manual.This information will not be updated. For testing, adjustment and repair procedures, always refer to the latest electronic service information.

Language: English
Format: PDF
Pages: 62
