The fourth generation of the brand flagship is, once again, the reference point defining Vorsprung durch Technik – thanks to a new design language, an innovative touch concept and the systematic electrification of the driveline. Not only that, the Audi A8 (type 4N)
is the world’s first production car to be developed for highly automated driving. Starting in 2018, Audi will successively bring piloted functions into production.

All units work in conjunction with the belt starter generator, which is the heart of the 48-volt electrical system. This mild hybrid technology (MHEV, mild hybrid electric vehicle)
enables the vehicle to coast with the engine off and to restart comfortably. It also has an advanced start-stop function and a high recuperation capacity of up to 12 kW.

Taken together, these measures further improve the already high fuel efficiency of the engines by up to 0.7 litres per 100 km during actual vehicle operation.

The mild hybrid drive in the new Audi A8 comprises 2 central building blocks. One of them is the water-cooled belt starter generator mounted to the end face of the engine. A high-performance poly V belt connects it to the crankshaft. The belt starter generator has a recuperation capacity of 12 kW and produces up to 60 Nm of torque.

The second component is a lithium-ion battery with a charge capacity of 10 Ah and a voltage capacity of 48 volts. The newly developed 48-volt electrical system is the main electrical system in the new large saloon. The 12-volt electrical system is coupled to
the main electrical system via a DC-to-DC converter. The lithiumion battery housed in the luggage compartment is about the same size as a large lead acid battery. A closed-loop air cooling system provides for thermal management.

The 48-volt MHEV technology is particularly comfortable and efficient. When the driver takes his foot off the accelerator at speed of between 55 and 160 kph, the car can coast for up to 40 seconds with the engine completely disengaged. The start-stop phase begins at 22 kph when coasting at low speed.
