Self Study Program 652 – Audi 4.0L V8 TDI engine of EA898 series

By Todd Mitchell

On: Tuesday, November 21, 2023 9:41 PM

Self Study Program 652 - Audi 4.0l V8 TDI engine of EA898 series

This comprehensive PDF file contains the official VAG Self-Study Program 652 (SSP 652), focused entirely on the design, function, and cutting-edge technology of the Audi 4.0-liter V8 TDI engine (engine family EA898). As a flagship diesel powerplant used in high-performance models like the Audi SQ7 (TDI), SQ8, and the A8, this engine was completely developed from the ground up to combine massive torque delivery with EU6 emissions compliance and high efficiency. This technical training manual is an absolute must-have for mechanics, diagnostic technicians, and VAG enthusiasts who need to understand the incredibly complex interactions between its triple-forced-induction setup and the 48-volt electrical system.

Please note: As a Self-Study Program, this document focuses on engineering design, mechanical layouts, and operational theory. It is not a step-by-step repair or workshop manual, though the theoretical knowledge it provides is invaluable for complex diagnostics on these intricate engines.

The manual covers the following key engineering topics in detail:

Engine Mechanics and Architecture: A detailed overview of the robust internal components required to handle 900 Nm of torque. It details the physical construction of the block, the cooling circuits, and the integration of the Audi Valvelift System (AVS). In a diesel first, the AVS is used on the exhaust camshaft to physically control which exhaust valves open, dictating which turbocharger receives exhaust gas.
Sequential Biturbo Charging: A deep dive into the complex exhaust-driven forced induction. It meticulously explains how the engine operates on a single “active” turbocharger at low RPMs (keeping one exhaust valve per cylinder closed) and uses a recirculation valve and AVS to seamlessly bring the second “passive” turbocharger online for maximum high-end power in biturbo mode.
The Electric Powered Compressor (EPC): The standout feature of the EA898. The manual provides a complete breakdown of this world-first production technology. It explains how the EPC, located downstream of the intercooler, spins its compressor wheel up to 70,000 rpm in under 250 milliseconds using an electric motor. This provides instant boost pressure when starting off or at low RPMs, completely eliminating turbo lag.
48-Volt Electrical Subsystem: Essential details on the power source required to run the EPC. It outlines the integration of the dedicated 48-volt lithium-ion battery and how it interacts with the vehicle’s standard electrical system to provide up to 7 kW of power to the electric compressor.
Fuel Delivery and Emissions: A comprehensive overview of the high-pressure Common Rail fuel injection system and the sophisticated exhaust gas treatment systems required to meet global emissions standards (including EU6 and ULEV125).

Whether you are trying to diagnose a fault in the recirculation valve between the turbos, understand the exact actuation of the 48V Electric Powered Compressor, or simply want to appreciate the engineering behind one of the most advanced V8 diesels ever produced, SSP 652 is a vital technical resource.

CONTENTS

Introduction
- Brief description and special features
- Specifications
- Engine concept with “inner hot side”
Engine mechanicals
- Engine block
- Timing gear
- Cylinder head
- Audi valvelift system (AVS)
- Crankcase ventilation system
Oil supply
- System overview
- Oil circuit
- Oil filter
- Oil pump
- Oil cooling
Exhaust gas recirculation
- Overview
- EGR cooler
Cooling system
- System overview
- Coolant module
Air supply and turbocharging
- Combined design cover with integrated air filter
- Intake system
- Intake manifold header
- Electric powered compressor (EPC)
- 48-volt electrical subsystem
- Charging group
- Charge-air pressure control
Fuel system
- System overview
- High-pressure fuel system
- SCR system
Exhaust system
- Overview
- Exhaust gas treatment module
- Ammonia slip catalyst (version for NAR)
Engine management
- System overview
Service
- Special tools and workshop equipment
Appendix
- Self study programmes

Language: English
Format: PDF
Pages: 48

Self Study Program 652 – Audi 4.0l V8 TDI engine of EA898 series PDF free online
