Passive safety

A new airbag control unit J234 was developed for occupant protection in the Audi Q7 (type 4M). It contains a sensor which measures rotation about the Z axis. In addition, the airbag control unit J234 now communicates via the FlexRay bus with other control units such as the ABS control unit J104. The ABS control unit J104 thus receives in real time data on rotation about the Z axis which is utilised by the Electronic Stability Control (ESC) system.
Depending on country and trim level, pyrotechnic seat belt tensioners can be installed in the 3rd seat row of the Audi Q7 as an option.

Active safety

Depending on country, 4 Audi pre sense functions are optional for the Audi Q7. In additional to Audi pre sense basic, these are:

  • pre sense rear
  • pre sense front
  • pre sense city

Audi pre sense city is able to warn the driver about vehicles and pedestrians and brake within system limitations. Audi pre sense front brings to the Audi Q7 new functions such as evasion assist and turn assist.

Infotainment

Audi offers various levels of the infotainment modules for the Audi Q7. MMI Radio plus is standard in Germany. This offers interfaces for external devices such as mobile phones or memory cards. The Audi sound system delivers excellent sound quality from its ten speakers. It is controlled using the MMI terminal on the center tunnel.

MMI navigation plus also includes the module Audi connect, which connects the Audi Q7 to the Internet via the LTE standard. Rear passengers can surf via the WiFi hotspot with download speeds of up to 100 Mbit/s and send and receive e-mail. The driver can use the customised Audi connect services ranging from online traffic information to navigation with Google Earth and Google Street View to online media streaming.

Learning objectives of this self study programme:

This self study programme describes the occupant protection and infotainment systems of the Audi Q7 (type 4M). Once you have completed this self study programme you will be able to answer questions on the following topics:

  • New passive safety features
  • New active safety features
  • Modifications to and new features of the infotainment system

CONTENTS

  • Passive safety
    • Overview
    • Components
    • System overview
    • Centre crash sensor for X/Y axis G858
    • Airbag control unit J234
    • Seat belts
    • Lap belt tensioner with buckle
  • Active safety
    • Audi pre-sense
    • Pre sense basic
    • Pre sense rear
    • Pre sense front
    • Pre sense city
    • Settings and displays
  • Infotainment
    • Overview of versions
    • Second-generation MIB Standard
    • MMI radio
    • MMI Radio plus
    • MMI Navigation plus
    • Audi connect (depending on market)
    • Control panel
    • Display mechanism
    • Audi phone box
    • Network system
    • Sound systems
    • Aerials overview
  • Appendix
    • Test your knowledge
    • Self study programmes

The Self Study Programme teaches a basic knowledge of the design and mode of operation of new models, new automotive components or new technologies.
It is not a Repair Manual! Figures are given for explanatory purposes only and refer to the data valid at the time of preparation of the SSP. This content is not updated.
For further information on maintenance and repair work, always refer to the current technical literature.

Language: English
Format: PDF
Pages: 72
