The e-up! is the first electric vehicle from Volkswagen to be mass produced. It also has other new features such as the brake system with brake energy recovery, and the 1-gear gearbox 0CZ which forms one unit together with the three-phase current drive. The maximum input torque of the 1-gear gearbox 0CZ is 210 Nm and the gearbox is quieter over the entire motor speed range.

The brake system with brake energy recovery has been developed especially for vehicles with three-phase current drive. Under certain circumstances, the three-phase current drive can cause a deceleration when in alternator mode. This means the e-up! is capable of electrical deceleration of up to 3.5 m/s2. The power and control electronics for the electric drive supplies the energy generated to the high-voltage battery.

CONTENTS

  • Introduction
    • An overview of the running gear
  • Running gear
    • The e-up! brake system
    • Electrical connection
  • Power transmission
    • 1-gear gearbox 0CZ
    • Gearbox mechanism
    • Lubricant circuit
    • Selector lever E313
    • Gear display
    • Activating the ready-to-drive system
  • Test your knowledge

The self-study programme presents the design and function of
new developments!
The content will not be updated.
Current testing, setting and repair instructions can be found in the provided service literature.

Language: English
Format: PDF
Pages: 28
