Self Study Program 113 – SEAT 1.6L 16v 77kW Engine

Self Study Program 113 – SEAT 1.6 L 16v 77kW Engine PDF free online

The 1.6 L 16v 77kW engine was fitted on SEAT models with the launch of the Ibiza 02 and Cordoba 03.

The highlight was the fitting of variable intake manifold timing to optimise the delivery of engine torque at different engine rpm levels.

The lubrication circuit is supplied by a self-adjusting pressure dependant pump and it has an integrated forced oil vapour breathing system.

A new feature is the incorporation of a coolant circuit in two separate sections, one for the cylinder head and one for engine block.

Each section is connected to the radiator through an independent thermostat.

The engine management system is the Motronic 2.5.20, whose functions together with the sensor and actuators allow compliance with the EU IV legislation.

CONTENTS

  • Characteristics
  • Mechanical details
  • Coolant circuit
  • Fuel circuit
  • Engine block breathing
  • Synoptic chart
  • Fuel injection
  • Ignition
  • Idle stabilization
  • Carbon canister system
  • Variable timing
  • EOBD
  • Wiring diagrams
  • Self Diagnosis

Note: The precise checking, adjustment and repair information is contained in Repair Manual and in the VAS 5051.
