Renault Premium DXI 450 FAULT CODES

Definition. Identification of the fault code. Make-up of a fault code: A fault code is made up of:

  • a “MID” code associated with a digital value to identify the ECU,
  • a “PID” or “PPID” or “SID” or “PSID” code associated with a digital value to identify the origin,
  • an “FMI” code associated with a digital value to identify the type of fault.

Identification of fault code – MID

MIDI28 G002 – Engine management ECU

MIDI 30 G020 – Automatic transmission ECU

MIDI 36 G005 – EBS braking management ECU

MIDI40 D001 – Principal information display

MIDI41 G100 – Datamax gateway ECU

MIDI 42 G101 – Communicator satellite ECU

MIDI44 G001 – Vehicle management ECU

MIDI 50 G004 – Air suspension ECU

MIDI63 G025 – Engine immobilizer ECU

MIDI 66 G104 – Tyre pressure monitoring ECU

MIDI 79 G018 – FMS – GATEWAY management ECU

MIDI 84 G027 – Piloted axle ECU

MIDI 85 G051 – Air production management ECU

MID214G026 -Alarm ECU

MID216 G012 – Lighting and signalling management ECU

MID220 D004 – Tachograph

MID222 G021 – Hydraulic retarder ECU

MID223 G019 – Gear selector ECU

MID249 G003 – Bodybuilding pre-arrangement management ECU

Identification of fault code – SID



It may happen that the listing below contains several codes possessing the same item number but each one making reference to a particular ECU. To make for easy read-out, it is necessary in this case to refer to the paragraph dealing with the ECU to be diagnosed.

The terms below are only used for one single ECU.

SID9 N° 2 axle LH side modulator

SID11 N° 3 axle LH side modulator

SID12 N° 3 axle RH side modulator

SID17 Front axle suspension position sensor

SID19 Drive axle suspension LH position sensor

SID21 Camshaft engine speed sensor

SID23 Front air spring air pressure sensor

SID24 Drive axle suspension RH air pressure sensor

SID25 Drive axle suspension LH air pressure sensor

SID26 Rear axle suspension air pressure sensor

SID28 Lift-up axle air spring air pressure sensor

SID32 Wastegate electrovalve

SID35 High range electrovalve

SID36 Low range electrovalve

SID37 High speed electrovalve

SID38 Low speed electrovalve

SID40 Electrovalve, external speed selector ram

SID42 High-pressure pump solenoid valve

SID50 Electrovalve, internal lateral control ram

SID51 Electrovalve, internal speed selector ram

SID52 Hydraulic system

SID58 Gearshift control system

SID59 Gear selection system

SID63 Output shaft speed sensor

SID66 Trailer brake control EBS modulator unit

SID67 Trailer modulator pressure sensor signal

SID68 Trailer modulator pressure sensor current supply voltage

SID71 1st axle RH side brake lining wear sensor

SID72 2nd axle LH side brake lining wear sensor

SID73 2nd axle RH side brake lining wear sensor

SID74 3rd axle LH side brake lining wear sensor

SID75 3rd axle RH side brake lining wear sensor

SID76 Brake pedal sensor unit

SID78 Fuel feed pump

SID211 Sensor(s) second current supply (5V+)

SID221 Internal power supply voltage sensor

SID229 Kick-down contact

SID230 Accelerator pedal “rest” position sensor 1

SID231 CAN command bus SAE J1939

SID232 Sensor(s) first current supply (5V+)

SID233 Control unit (2)

SID240 Program memory

SID246 Brake pedal contact

SID250 Information bus SAE J1587

SID251 Electrical power supply

SID253 Calibration memory

SID254 Control unit



The terms below are common to several ECUs. Refer to the part concerning the ECU involved.

G002 Engine management ECU

SID1 N° 1 cylinder injector solenoid valve

SID2 N° 2 cylinder injector solenoid valve

SID3 N° 3 cylinder injector solenoid valve

SID4 N° 4 cylinder injector solenoid valve

SID5 N° 5 cylinder injector solenoid valve

SID6 N° 6 cylinder injector solenoid valve

SID18 Water separator bleed valve

SID22 Flywheel speed sensor

SID33 Engine cooling fan speed regulation solenoid valve

SID39 Starting relay

SID70 Air preheating resistor

G005 EBS braking management ECU

SID1 1st axle, LH roadwheel wheel speed sensor

SID2 1st axle RH roadwheel wheel speed sensor

SID3 2nd axle LH roadwheel wheel speed sensor

SID4 2nd axle RH roadwheel wheel speed sensor

SID5 3rd axle LH roadwheel wheel speed sensor

SID6 3rd axle RH roadwheel wheel speed sensor

SID7 № 1 axle LH side modulator

SID8 № 1 axle RH side modulator

SID10 № 2 axle RH side modulator

SID39 Electrovalve, external lateral control ram

SID22 Wheel speed sensor

SID70 1st axle LH side brake lining wear sensor

G004 Air suspension ECU

SID3 Drive axle suspension electrovalve (RH side)

SID4 Drive axle suspension electrovalve (LH side)

SID5 Rear axle suspension electrovalve

SID7 Drive axle main suspension electrovalve

SID8 Rear axle main suspension electrovalve

SID10 Lift-up axle air spring control electrovalve

SID18 Drive axle suspension RH position sensor

SID33 Air suspension command remote control

G021 Hydraulic retarder ECU

SID2 Retarder PWM solenoid valve

G025 Engine immobilizer ECU

SID1 Transmitter / receiver antenna

SID2 Front suspension electrovalve

Identification of fault code – PSID



It may happen that the listing below contains several codes possessing the same item number but each one making reference to a particular ECU. To make for easy read-out, it is necessary in this case to refer to the paragraph dealing with the ECU to be diagnosed.

The terms below are only used for one single ECU.

PSID31 CAN engine information command bus SAE J1939

PSID33 “MENU/OK” control

PSID34 “EXIT” control

PSID35 “VOL+” control

PSID38 “SEARCH” control

PSID40 Inadequate AdBlue quality

PSID45 High nitrogen oxides concentration – Cause unknown

PSID46 Nitrogen oxides monitoring fault

PSID51 Chassis lateral acceleration sensor

PSID52 Yaw angle sensor

PSID53 Lockover angle sensor

PSID59 ABS electrovalve control

PSID60 1st axle LH side ABS electrovalve

PSID61 1st axle LH side ABS electrovalve

PSID62 1st axle RH side ABS electrovalve

PSID63 1st axle RH side ABS electrovalve

PSID64 ABS electrovalves earth

PSID65 EBS braking management ECU modules configuration

PSID66 4th axle LH side modulator

PSID67 4th axle RH side modulator

PSID70 4th axle LH roadwheel wheel speed sensor

PSID71 4th axle RH roadwheel wheel speed sensor

PSID74 Brake lining wear sensor, 4th axle, LH side

PSID77 AdBlue top-up pump management module EEPROM

PSID81 Rear wheels diff. lock electrovalve

PSID82 AdBlue heating pump

PSID84 AdBlue heating resistor (in circuit: pump module to

dosing solenoid valve)

PSID87 Motor-driven pump speed sensor

PSID88 Trailer brake control EBS modulator unit (inlet valve)

PSID91 AdBlue consumption

PSID94 AdBlue temperature internal sensor

PSID96 Fuel high pressure sensor

PSID97 High-pressure pump solenoid valve

PSID98 Turbo charge air system

PSID101 AdBlue injector cooling control electrovalve

PSID102 AdBlue heating resistor (in circuit: dosing solenoid valve to pump module)

PSID103 AdBlue heating resistor (in circuit: reservoir to pump module)

PSID104 AdBlue heating resistor ((in circuit: pump module to reservoir)

PSID106 Catalytic converter

PSID107 AdBlue heating resistor (in pump filter)

PSID115 AdBlue tank empty

PSID119 ESP sensors current supply

PSID121 ABS function

PSID123 EBS modules data link

PSID124 ESP sensors data link

PSID161 NoVIN response

PSID162 Incorrect VIN response

PSID200 Engine management ECU data bus

PSID201 Vehicle management ECU data bus

PSID202 Principal information display data bus

PSID203 Principal information display data bus

PSID204 EBS braking management ECU data bus

PSID205 Automatic gearbox ECU data bus

PSID206 Retarder management ECU data bus

PSID207 Gear selector ECU data bus

PSID208 Air suspension ECU data bus

PSID210 Lighting and signalling management ECU data bus

PSID212 Tachograph data bus

PSID214 Bodybuilding prearrangements management ECU data bus

PSID215 Pilot-controlled 2nd axle management ECU data bus

PSID227 Air production management ECU data bus

PSID229 AdBlue top-up management pump module data bus

PSID230 Software fault

PSID232 CAN command data bus SAE J1939

PSID233 Engine immobilizer ECU data bus

PSID234 Alarm ECU data bus

PSID236 FMS – GATEWAY management ECU data bus

PSID237 Datamax Gateway ECU data bus

PSID247 Tyre pressure monitoring ECU data bus

PSID254 ECU programming authorization signal

The terms below are common to several ECUs. Refer to the part concerning the ECU involved.

D001 Principal information display

PSID36 “VOL-” control

PSID37 “SOURCE” control

PSID48 Control “AF”

D004 Tachograph

PSID1 Engine shut-down speed signals reception

PSID2 Recording unit

PSID3 Date and hour

PSID4 Speed pulse output

PSID6 Tachograph speed sensor

PSID7 Tachograph keypad

PSID8 Printer

PSID9 Tachograph display

PSID10 Chart 1 reader

PSID11 Chart 2 reader

PSID12 Speed sensor current supply for tachograph

PSID13 Driving without recording media

PSID14 Insertion of chart in chart 1 reader while on the road

PSID15 Insertion of chart in chart 2 reader while on the road

PSID22 Recording error

PSID24 Tachograph tray open

PSID25 Tachograph chart tray

PSID25 Tachograph printer tray open

PSID26 Exceeding driving time (4 hours 15 mins)

PSID26 Chart 1 absence

PSID27 Exceeding driving time (4 hours 30 mins)

PSID27 Chart 2 absence

PSID28 Tachograph platen and chart parameters update

PSID28 Excessive speed

PSID29 Faulty recorder

PSID30 Recording system lifting device

G001 Vehicle management ECU

PSID2 Accelerator pedal “rest” position sensor 2

PSID4 Retarder control

PSID5 Stop lights switch contact

PSID7 Speed information

PSID8 Gearbox neutral state

PSID9 Clutch state

PSID10 Reversing lights output

PSID11 Stop lights output

PSID12 PTO № 1 defective engagement conditions

PSID13 Reverse gear engagement electrovalve

PSID14 DATAMAX error

PSID19 Parking brake state output

PSID20 Direct power take-off № 1

PSID21 CAN command bus SAE J1939-1

PSID22 CAN command bus SAE J1939-2

G002 Engine management ECU

PSID41 AdBlue consumption too low

PSID42 AdBlue dosing interruption

PSID43 Poor exhaust gas recycling

PSID44 Disabling of exhaust gas recycling

PSID75 Engine coolant circuit by-pass solenoid valve

PSID85 AdBlue top-up pump management module main relay

PSID86 AdBlue top-up pump management module current supply contact

PSID89 AdBlue top-up dosing solenoid valve

PSID90 AdBlue top-up management system

PSID105 AdBlue return solenoid valve

G003 Bodybuilder pre-arrangement management ECU

PSID1 Available power supply (mini PLC № 1 output)

PSID2 Available power supply (mini PLC output 2)

PSID3 PTO № 2 defective engagement conditions

PSID4 PTO № 3 defective engagement conditions

PSID5 PTO № 2 engagement on standby

PSID6 РТО № 3 engagement on standby

PSID9 PTO № 2 electrovalve

PSID10 PTO №3 electrovalve

PSID11 Available power supply (engine starting information)

PSID12 Available power supply (engine alert)

PSID13 Transfer box low speed electrovalve

PSID14 Module signal input

PSID15 Transfer box neutral electrovalve

PSID15 Transfer box high speed electrovalve

G004 Air suspension ECU

PSID1 Vehicle attitude level sensor current supply

PSID2 Suspension air spring pressure sensor current supply

PSID3 Second rear axle lift-up control

PSID19 Front suspension pneumatic circuit

PSID20 Drive axle suspension pneumatic circuit (LH side)

PSID21 Drive axle suspension pneumatic circuit (RH side)

PSID22 Drive axle suspension pneumatic circuit

PSID23 Second rear axle suspension pneumatic circuit

PSID24 Rear axle lift-up air spring pneumatic circuit

G005 EBS braking management ECU

PSID21 Trailer braking system

PSID22 EBS braking management ECU current supply voltage

PSID23 Trailer braking system data bus

PSID25 EBS braking management ECU test or programming

PSID28 Worn brake linings

PSID30 Brakes low supply pressure

PSID37 Chassis lateral acceleration sensor calibration

PSID41 Passive ESP

PSID48 Braking capacity

PSID75 Brake lining wear sensor, 4th axle, RH side

PSID85 Hill-start function warning light

PSID86 Brake pedal sensor unit

PSID89 Trailer brake control EBS modulator unit (exhaust valve)

PSID90 Trailer brake control EBS modulator unit (safeguard valve)

G012 Lighting and signalling management ECU

PSID2 LH front dipped beam headlight

PSID4 RH front dipped beam headlight

PSID13 LH front direction indicator light(s)

PSID14 RH front direction indicator light(s)

PSID15 LH rear direction indicator light(s)

G019 Gear selector ECU

PSID100 Gear selector

PSID9 Gear selector position sensor

PSID36 Current supply relay

G020 Automatic transmission ECU

PSID1 Fast clutch engagement electrovalve

PSID2 Slow clutch engagement electrovalve

PSID3 Fast clutch release electrovalve

PSID4 Slow clutch release electrovalve

PSID5 Clutch fast engagement and release electrovalves earth

PSID6 Clutch fast engagement and release electrovalves earth

PSID12 1st gear engagement electrovalve

PSID13 PTO № 1 engagement on standby

PSID14 3rd gear engagement electrovalve

PSID15 2nd gear engagement electrovalve

PSID17 Gearshifting force control solenoid valve

PSID18 Hydraulic pump electric motor

PSID20 PTO № 1 engagement electrovalve

PSID21 PTO № 2 engagement electrovalve

PSID22 Intermediate shaft brake electrovalve

PSID23 Splitter engagement system

PSID24 Range change engagement system

PSID25 1st/Reverse gear engagement system

PSID26 2nd / 3rd gear engagement system

PSID27 Clutch system

PSID28 Intermediate shaft brake

G026 Alarm ECU

PSID1 Cab door(s) open information position sensors

PSID2 Earth

PSID3 Van door(s) open information position sensor(s)

PSID4 Trailer parking brake electrovalve

PSID5 Trailer line disconnected or damaged

PSID6 Ultrasonic movement sensor

PSID7 Alarm siren

PSID9 Cab tilting sensor

PSID10 Communication line between alarm ECU and doors central closing ECU

PSID11 Communication line between alarm ECU and lighting management ECU

PSID12 ECU in maintenance mode

PSID13 Starting attempt with alarm activated

PSID22 Communication line between alarm ECU and van alarm module

G027 Piloted axle ECU

PSID1 Oil reservoir level sensor

PSID2 Safety solenoid valve

PSID3 LH and RH control solenoid valves

PSID4 Rear axle lockover angle deviation

G051 Air production management ECU

PSID1 Main electrovalve

PSID2 Compressor activation solenoid valve

PSID3 Regeneration electrovalve

PSID4 Trailer door(s) open information position sensor(s)

PSID5 Heating actuator

PSID6 Front circuit pressure sensor

PSID7 Rear circuit pressure sensor

PSID8 Trailer circuit pressure sensor

PSID10 Electrovalves

PSID11 Pressure sensors

PSID13 Pressure limiter PL34

PSID19 Leak in air circuit and at dehydrator cartridge

PSID20 Significant leak in air circuit and at dehydrator cartridge

PSID21 Fault on air circuit and dehydrator cartridge

PSID22 Compressor

PSID30 System pressure

G101 Communicator satellite ECU

PSID3 DATAMAX GATEWAY ECU message sending failure

PSID4 GPS module

PSID5 DSP (Digital Signal Processor) module

PSID6 Satellite module

PSID100 Display protocol

G102 Onboard management ECU

PSID3 DATAMAX GATEWAY ECU message sending failure PSID4 GPS module

PSID5 DSP (Digital Signal Processor) module

PSID6 Clutch fast engagement and release electrovalves earth G104 Tyre pressures monitoring ECU

PSID1 1st axle № 1 roadwheel from the left pressure sensor PSID2 Pressure sensor, first axle, wheel 2 from the left

PSID4 1st axle № 2 roadwheel from the left pressure sensor PSID5 2nd axle № 1 roadwheel from the left pressure sensor PSID6 2nd axle № 2 roadwheel from the left pressure sensor PSID7 2nd axle № 3 roadwheel from the left pressure sensor PSID8 2nd axle № 4 roadwheel from the left pressure sensor PSID9 3rd axle № 1 roadwheel from the left pressure sensor PSID10 3rd axle № 2 roadwheel from the left pressure sensor PSID11 3rd axle № 3 roadwheel from the left pressure sensor PSID12 3rd axle № 4 roadwheel from the left pressure sensor PSID13 Pressure sensor, fourth axle, wheel 1 from the left PSID14 Pressure sensor, fourth axle, wheel 2 from the left PSID15 Pressure sensor, fourth axle, wheel 3 from the left PSID16 Pressure sensor, fourth axle, wheel 4 from the left PSID21 1st axle № 1 trailer module

PSID22 2nd axle trailer module 1

PSID23 3rd axle trailer module 1 PSID24 4th axle trailer module 1 PSID25 5th axle trailer module 1 PSID26 1st axle trailer module 2 PSID27 2nd axle trailer module 2 PSID28 3rd axle trailer module 2 PSID29 4th axle trailer module 2 PSID30 5th axle trailer module 2 H014 Radio set

PSID2 LH front audio output PSID3 RH front audio output PSID4 LH rear audio output PSID5 RH rear audio output PSID6 External amplifier control

PSID7 SDAR audio antenna

PSID8 RF audio antenna

PSID9 Audio USB

PSID10 CD

PSID12 Auxiliary input 1

PSID13 Auxiliary input 2

PSID14 Mono input 1

PSID15 Mono input 2

PSID16 TA I clock button

PSID17 CD ejection button

PSID18 RADIO button

PSID19 CD button

PSID20 ON / sound volume button

PSID21 Navigation buttons

PSID22 AUDIO button

PSID23 MENU button

PSID24 Pre-selection buttons

PSID25 Bluetooth

PSID26 Digital Walkman

Identification of fault code – PID –



It may happen that the listing below contains several codes possessing the same item number but each one making reference to a particular ECU. To make for easy read-out, it is necessary in this case to refer to the paragraph dealing with the ECU to be diagnosed. PID26 Engine cooling fan speed PID31 Range change ram position PID32 Splitter cylinder position PID33 Clutch cylinder position PID36 Clutch plates wear level PID37 Gearbox air pressure PID45 Air preheat relay state PID70 Parking brake contact state PID84 Vehicle speed

PID91 Accelerator pedal position

PID93 Output torque

PID94 Fuel feed pressure

PID96 Fuel level

PID97 Water ingress into fuel indication

PID98 Engine oil level

PID100 Engine oil pressure

PID102 Turbo charge air pressure

PID105 Turbo charge air temperature

PID107 Air filter low pressure

PID108 Atmospheric pressure

PID110 Engine coolant temperature

PID111 Engine coolant level

PID120 Retarder oil temperature

PID152 Number of resets

PID153 Crankcase pressure

PID158 Battery voltage(s)

PID160 Secondary shaft rotating speed

PID161 Intermediate shaft rotating speed

PID164 High-pressure rail pressure

PID171 External temperature

PID175 Engine oil temperature

PID177 Gearbox oil temperature

PID190 Engine speed

PID224 Vehicle security code

PID228 Vehicle speed sensor calibration

PID245 Vehicle total distance

PID252 Date



Identification of fault code – PPID

It may happen that the listing below contains several codes possessing the same item number but each one making reference to a particular ECU. To make for easy read-out, it is necessary in this case to refer to the paragraph dealing with the ECU to be diagnosed.

PPID3 Starting relay output state

PPID6 Engine stop switch

PPID10 1st/Reverse gear selector ram position

PPID11 2nd/3rd gear selector ram position

PPID31 Retarder air pressure

PPID50 Clutch plates load

PPID51 Clutch engagement point

PPID54 ECU 5V+ output state

PPID55 ECU temperature

PPID60 Accelerator pedal contacts state

PPID69 Idling contact stored in buffer memory

PPID70 Accelerator pedal or clutch pedal “rest” position sensors current supply

PPID71 Cruise control and engine speed regulator, retarders coupling and fuel ingress water bleed current supply

PPID72 Accelerator pedal and retarders control sensor current supply

PPID74 Vehicle and engine control ECUs power supply relays state

PPID75 Range change safety electrovalve

PPID79 Gear selector rail safety electrovalve

PPID122 Compression brake position

PPID124 Exhaust pressure regulator

PPID140 Vehicle inclination

PPID181 Front axle lockover angle

PPID182 Rear axle lockover angle

PPID210 Retarder modulated control electrovalve state

PPID258 Engine speed control mode: rotary switch

PPID270 Exhaust gases NOx rate

PPID273 AdBlue solution pressure

PPID274 AdBlue reservoir temperature

PPID275 AdBlue filter temperature

PPID278 AdBlue solution reservoir level

PPID294 Trailer circuit air pressure

PPID295 Failsafe neutral position

PPID302 Rearview mirrors heating resistors power supply relay

PPID305 Front braking air pressure

PPID306 Rear braking air pressure

PPID385 AdBlue ECU current supply voltage

PPID386 Catalytic converter upstream temperature

PPID387 Temperature downstream from catalytic converter

PPID434 Dosing valve temperature

PPID435 Effective torque

PPID463 Vehicle attitude level

PPID474 Engine immobilizer PIN code / transponders pairing procedure Identification of fault code – FMI

FMI-0 Data existing but above the normal operating band

FMI-1 Data existing but below the normal operating band

FMI-2 Data inexact or intermittent

FMI-3 Voltage abnormally high or short-circuit to a higher voltage

FMI-4 Voltage abnormally low or short-circuit to a lower voltage or short-circuit to earth

FMI-5 Current abnormally low or cut-off

FMI-6 Current abnormally high or short-circuit to earth

FMI-7 Inexact response originating from the mechanical system

FMI-8 Abnormal frequency

FMI-9 Abnormal updating rate

FMI-10 Variations abnormally high

FMI-11 Fault not identified

FMI-12 Defective unit or component

FMI-13 Values outside calibration

FMI-14 Special instructions

FMI-15 Reserved for future use
