Renault Diagnostic Trouble Codes
Renault Diagnostic Fault Codes List
LP3500 Engine immobilizer circuit
P3501 Communication error with climate
P3502 Error communicating with BVA (cruise)
P3503 Error communicating with ABS
P3504 Refrigerant pressure sensor circuit
P3505 Fuel System Error
P3506 The ignition coil circuit of cylinders No. 1 and No. 4 is closed to ground
P3507 The ignition coil circuit of cylinders No. 2 and No. 3 is closed to ground
P3508 Error The ignition coil circuit of cylinders No. 1 and No. 4
P3509 Error The ignition coil circuit of cylinders No. 2 and No. 3
P3511 Actuator relay control circuit closed to ground
P3515 The purge purge solenoid valve circuit is closed to + bat
P3517 On-Board Diagnostic System Warning Lantern Circuit
P3518 Coolant temperature warning light circuit closed at + bat
P3519 Coolant temperature warning light circuit closed with ground
P3520 Coolant temperature warning light circuit broken
P3521 Coolant Temperature Warning Lamp Circuit
P3522 Idle speed control circuit closed at + bat
P3523 Electronic pedal circuit breakage
P3524 Electronic Pedal Circuit Shorted to +12 Volts
P3525 Electronic Pedal Circuit Short to Ground
P3526 Electronic Pedal Circuit Malfunction
P3527 Control circuit climate clipping
P3528 Control circuit climate closure At +12 Volts
P3529 Control Circuit Climate Failure to Ground
P3530 Control circuit climate malfunction
