Nissan RE5RO5A – ATSG (Automatic Transmission Service Group)

The RE5RO5A is a 5 speed, rear wheel drive transmission. It uses full electronic controls for the upshifts and downshifts, with 5th gear being overdrive. The individual gear ratios are achieved through 3 planetary gear sets connected one behind the other. The components of the planetary gear sets are driven or held by means of six multiple plate clutch packs, 1 band, and three sprags. The RE5RO5A comes in 2WD and 4WD versions, and is manufactured by JATCO.

To minimize fuel consumption, the torque converter clutch is controlled by the TCM, depending on throttle position and vehicle speed. These units are currently found in In

  • Nissan 350Z, 3.5L V6, 2003-2006
  • Nissan Armada, 5.6L V8, 2004-2007
  • Nissan Frontier, 2.5L L4, 2005-2007
  • Nissan Frontier, 4.0L V6, 2005-2007
  • Nissan Xterra, 4.0L V6, 2005-2007
  • Nissan Pathfinder, 4.0L V6, 2005-2007
  • Nissan Titan, 5.6L V8, 2004-2007
  • Infiniti FX35, 3.5L V6, 2003-2007
  • Infiniti G35, 3.5L V6, 2003-2007
  • Infiniti M35, 3.5L V6, 2005-2007
  • Infiniti FX45, 4.5L V8, 2003-2007
  • Infiniti M45, 4.5L V8, 2005-2007
  • Infiniti Q45, 4.5L V8, 2002-2007
  • Infiniti QX56, 5.6L V8, 2004-2007

CONTENTS

  • GENERAL DESCRIPTION AND IDENTIFICATION TAG LOCATION
  • INTERNAL COMPONENTS LOCATION
  • COMPONENT APPLICATION CHART AND FLUID REQUIREMENTS
  • ELECTRONIC COMPONENT DESCRIPTION
  • ELECTRICAL CONNECTORS AND WIRE HARNESS “EXTERNAL TCM” MODELS
  • SOLENOID RESISTANCE CHART
  • ELECTRICAL CONNECTORS AND WIRE HARNESS “INTERNAL TCM” MODELS
  • WIRE SCHEMATIC “INTERNAL TCM” MODELS
  • WIRE SCHEMATIC “EXTERNAL TCM” MODELS
  • DIAGNOSTIC TROUBLE CODE (DTC) DESCRIPTION
  • FREEWHEEL DIRECTION FOR ALL SPRAGS
  • CASE PASSAGE IDENTIFICATION
  • LINE PRESSURE TAP LOCATIONS AND SPECIFICATIONS
  • TRANSMISSION DISASSEMBLY
  • COMPONENT REBUILD
    • TRANSMISSION CASE ASSEMBLY
    • OIL PUMP ASSEMBLY
    • OUTPUT SHAFT
    • INPUT HOUSING ASSEMBLY
    • FRONT PLANETARY SUN GEAR AND DRUM ASSEMBLY
    • 1ST SPRAG AND SUN GEAR SHAFT ASSEMBLY
    • DRUM SUPPORT ASSEMBLY
    • HIGH AND LOW/REVERSE CLUTCH HOUSING ASSEMBLY
    • DIRECT CLUTCH HOUSING ASSEMBLY
    • 4WD ADAPTER HOUSING/EXTENSION HOUSING
    • FORWARD SPRAG ASSEMBLY
    • VALVE BODY ASSEMBLY
    • CHECKBALL LOCATIONS FOR “2002-MID 2004” MODELS
    • CHECKBALL LOCATIONS FOR “MID 2004-2008” MODELS
  • TRANSMISSION ASSEMBLY
  • REVERSE BRAKE CLUTCH “N” SPRING LOCATION
  • OUTPUT/REVOLUTION SPEED SENSOR TESTING
  • FRONT BRAKE BAND ADJUSTMENT
  • END PLAY SPECIFICATIONS
  • CORRECT WIRE HARNESS INSTALLATION FOR “INTERNAL TCM” MODELS
  • THRUST BEARING, THRUST BEARING RACE, AND THRUST WASHER IDENTIFICATION
  • TORQUE SPECIFICATIONS
