Mitsubishi 4a9 Engine Overhaul

Mitsubishi 4a9 Engine Overhaul PDF free online

The Mitsubishi 4A9 engine is the newest family range of all-alloy inline four-cylinder engines from Mitsubishi Motors, introduced in the 2004 version of their Mitsubishi Colt supermini, and built by DaimlerChrysler-owned MDC Power in Germany (previously a joint venture).

The engine project was begun as a joint effort by Mitsubishi Motors and DaimlerChrysler (DCX), with Mitsubishi handling the development of the engines and MDC Power GmbH, a company previously jointly established by Mitsubishi and DCX, handling production. The 4A9 is Mitsubishi’s first four-cylinder engine family to adopt a high-pressure die-cast aluminum block.

All engines developed within this family have aluminum cylinder block and head, four valves per cylinder, double overhead camshaft layouts, and MIVEC continuous variable valve timing (intake only).

CONTENTS

  • GENERAL INFORMATION
  • GENERAL SPECIFICATIONS
  • SERVICE SPECIFICATIONS
  • TORQUE SPECIFICATIONS
  • SEALANTS
  • SPECIAL TOOLS
  • ALTERNATOR AND IGNITION SYSTEM
    • REMOVAL AND INSTALLATION
  • FUEL AND EMISSION PARTS
    • REMOVAL AND INSTALLATION
  • INLET MANIFOLD
    • REMOVAL AND INSTALLATION
  • EXHAUST MANIFOLD
    • REMOVAL AND INSTALLATION
  • OIL PAN AND TIMING CHAIN CASE
    • REMOVAL AND INSTALLATION
  • TIMING CHAIN
    • REMOVAL AND INSTALLATION
    • INSPECTION.
  • CAMSHAFT
    • REMOVAL AND INSTALLATION
    • INSPECTION
  • CYLINDER HEAD AND VALVES
    • REMOVAL AND INSTALLATION
    • INSPECTION.
  • PISTON AND CONNECTING ROD
    • REMOVAL AND INSTALLATION
    • INSPECTION.
  • CRANKSHAFT AND CYLINDER BLOCK
    • REMOVAL AND INSTALLATION
    • INSPECTION

Language: English
Format: PDF
Pages: 51

Mitsubishi 4a9 Engine Overhaul PDF free online
