Mazda G4A-EL Transmission Repair Manual – ATSG

Mazda

This manual contains information on diagnosing, teardown and assembly of this unit. The Mazda G4A four speed automatic transaxle can come with hydraulic shift control or computer control. Although both units share common parts there are many major differences. The computer control (EL) unit does not have a governor assembly, but has a heavy wire harness by the inhibitor switch that makes this unit readily identifiable. This unit has a converter clutch.

SPECIFICATIONS
POWERFLOW
TROUBLE SHOOTING
COMPUTER CHECKS
TESTING
PRESSURE TEST
TEARDOWN
PUMP
VALVE BODY
FLUID DRIVE
ASSEMBLY

Language: English
Format: PDF
Pages: 116

Mazda G4A-EL Transmission Repair Manual – ATSG PDF free online

Mazda G4A-EL Transmission Repair Manual – ATSG

CONTENTS
