Mazda 626 RF Turbo Workshop Manual

This manual contains the changes and/or additions relating to on-vehicle service and diagnosis procedures for the Mazda 626 and 626 Station Wagon. For proper repair and maintenance, a thorough familiarization with this manual is important, and it should always be kept in a handy place for quick and easy reference.

All the contents of this manual, including drawings and specifications, are the latest available at the time of printing. As modifications affecting repair or maintenance occur, relevant information supplementary to this volume will be made available at Mazda dealers. This manual should be kept up-to-date.

JMZ G F 12R2, JMZ G F 12T2, JMZ G F 14R2, JMZ G F 1 4T2, JMZ GW19R2, JMZ GW 19T2, JMZ GW69R2, JMZ GW69T2

CONTENTS

  • General Information
  • Engine FP, FS, FS (Hi-power)
  • Engine RF Turbo, RF Turbo (Hl-power)
  • Lubrication System
  • Cooling System
  • Fuel and Emission Control Systems FP, FS, FS (Hi-power)
  • Fuel and Emission Control Systems RF Turbo, RF Turbo (Hi-power)
  • Engine Electrical System
  • Clutch
  • Manual Transaxle
  • Automatic Transaxle
  • Front and Rear Axles
  • Steering System
  • Braking System
  • Suspension
  • Body
  • Body Electrical System
  • Heater and Air Conditioner Systems
  • Technical Data
  • Special Tools

Language: English
Format: PDF
Pages: 270
