Land Rover Frelander 2 2006 – 2010 Repair Manual and Wirig Diagrams
This manual has been written in a format that is designed to meet the needs of Land Rover technicians worldwide and to assist them in the efficient repair and maintenance of Land Rover vehicles. This manual provides descriptions and methods for accomplishing adjustment, service and repair work using tested and effective procedures. Following these procedures will help ensure product reliability.
Workshop Manual Organization
The five main sections, together with the areas which they cover are given below:
- Section 1 – General Information.
- Section 2 – Chassis.
- Section 3 – Powertrain.
- Section 4 – Electrical.
- Section 5 – Body and Paint.
Sub-section numbers appear after the initial section number, for example, Section 412-01 covers Climate Control, which is part of the electrical section.
In the number given above, the first digit of the number ‘4’ indicates the section i.e. Electrical. The second and third digits ’12’ of the number indicate the vehicle system i.e. Climate Control.
Language: English
File: PDF
Pages: 3229
Land Rover Frelander 2 2006 – 2010 Repair Manual and Wirig Diagrams
