Jeep CJ DJ Service Repair Manual

JeeJl UNIVERSAL, 4-WREEL DRIVE, CJ-2A, CJ-38, CJ-3A, CJ-5. JeeJ! DISPATCHER, 2-WHEEL DRIVE, DJ-3A
CJ-6. FORM SM-1002-R6. This manual is provided for the guidance of all automotive service men, vehicle owners, and service salesmen who repair, maintain, or adjust the ‘Jeep’ Universal and ‘Jeep’. Dispatcher. The information herein was prepared from the service man’s viewpoint to give him the accurate and concise data he may need to service the entire vehicle.

The information is not elementary as it is intended for automotive service men who are familiar with
automotive construction and repair in general. It is not intended, nor would it be possible in such limited space, to cover every possible repair that he may encounter. All specifications are in accord  with Engineering Specifications and should be adhered to in all work on the vehicle.

The manual sections follow logical division into major components of the vehicles. The first page of each section has a detailed index of the contents of that section. Subject matter covers all models included in this manual unless an exception for a particular model is specifically mentioned.

Specifications and components covered were for standard production models of ‘Jeep’ Vehicles
current at the time the manual was approved for printing. Kaiser ‘Jeep’ Corporation reserves the
right to discontinue models at any time or change specifications or design of any of its models with-
out notice and without incurring any obligation.

This manual covers all standard production ‘Jeep’ Universal and ‘Jeep’ Dispatcher models currently
being produced at the time this manual was approved fdr publication. Significant changes made
in each model sitice it was first produced are included in the manual.

A description of each model follows. General specifications for each model are listed in Par. A-17. Detailed specifications covering major vehicle units are listed at the end of each section of the. manual.

CJ-2A -·This is a 4-wheel-drive ‘Jeep’ Universal. It has a four-cylinder, L-head engine. This model is no longer in current production.

CJ-3A -This is a 4-wheel-drive ‘Jeep’ Universal. It has a four-cylinder, F -head engine. This model is no longer in current productiop.

CJ-3B —:-This is a 4-wheel-drive ‘Jeep’ Universal. It has a four-cylinder, F-head engine.

CJ-5 -This is a 4-wheel-drive ‘Jeep’ Universal. It has a four-cylinder, F-head engine.

CJ-6 -This is a 4-wheel-drive ‘Jeep’ Universal. It has a four-cylinder, F-head engine.

DJ-3A– This is a 2-wheel-drive ‘Jeep’ Dispatcher. It has a four-cylinder, L-head engine. It comes as eith~r an open body model or has a “Surrey” top.

CONTENTS

  • General Data
  • Lubrication
  • Tune-Up
  • L-Head Engine
  • F-Head Engine
  • Fuel System
  • Exhaust System
  • Cooling System
  • Electrical
  • Clutch
  • Transmission Transfer Case
  • Propeller Shafts
  • Front Axle
  • Rear Axle
  • Steering
  • Brakes
  • Wheels
  • Frame
  • Springs Shock Absorbers
  • Body
  • Miscellaneous

Language: English
Format: PDF
Pages: 281

Jeep CJ DJ Service Repair Manual
