JCB Tractor, Backhoe Loader Error Codes List DTC (Flashing codes)

P0087 (flashing code 227) shared sump low pressure fault (for pump without pressure supply)

The main fault symptoms

• Engine severe vibration.

• idling unstable

• Output Fall

• exhaust smoke

• It may be too large output



P0088 (flashing code 118) shared the tank pressure is abnormally high (first or second stage)

The main fault symptoms

• Engine severe vibration

• idle instability

• Output Fall

• channeling gas engine failure

• exhaust smoke

• It may be too large output



P0089 (flashing code 151) shared the tank pressure failure (for pump pressure supply is too large)

The main fault symptoms

• Engine severe vibration

• idle instability

• Output Fall

• channeling gas engine failure

• exhaust smoke

• It may be too large output

P0090 (flashing code 247) SCV drive system open, + B short circuit or shorted to ground

The main fault symptoms

• Depending on the open / short situations, there may be an engine stall and / or launch

Machine channeling gas.

• exhaust smoke

• Output is too large



P0107 (flashing code 71) atmospheric pressure sensor circuit input low (open or shorted to ground)

The main fault symptoms

Due to spare the equivalent altitude 2000 m (6562 ft)

• exhaust smoke at high altitude.

• insufficient output at low altitude



P0108 (flashing code 71) atmospheric pressure sensor circuit input high (+ 5V shorted)

The main fault symptoms

Due to spare the equivalent altitude 2000 m (6562 ft)

• The high altitude exhaust smoke

• lack of low altitude output



P0112 (flashing code 22) intake air temperature sensor fault (low voltage fault, earth fault, short circuit)

The main fault symptoms

• When cold starting, may exhaust white smoke.

P0113 (flashing code 22) intake air temperature sensor fault (the fault to a high voltage power supply circuit open or shorted)

The main fault symptoms

• When cold starting, may exhaust white smoke.



P0117 (flashing code 23) engine coolant temperature sensor fault (low voltage fault, earth fault, short circuit)

The main fault symptoms

• In the normal temperature: There may exhaust smoke, engine combustion and a great

Noise.

• In low ambient temperature during idle: There may be unstable idle, launched

Machine stall, row of white smoke.



P0118 (flashing code 23) engine coolant temperature sensor input high (to power open or short)

The main fault symptoms

• In the normal temperature: There may exhaust smoke, engine combustion and a great

Noise.

• At low atmospheric temperatures during idle: There may be unstable idle, hair

Motivation stall, row of white smoke.



P0182 (flashing code 211) Fuel temperature sensor fault (low voltage faults, shorted to ground)

The main fault symptoms

Operability affected.



P0183 (flashing code 211) Fuel temperature sensor fault (high voltage failure, power supply circuit is open or shorted)



P0192 (flashing code 245) shared the tank pressure sensor fault (low voltage fault, short circuit)

The main fault symptoms

• There may be an engine stall

• output reduction



P0193 (flashing code 245) rail pressure sensor fault (high voltage fault)

The main fault symptoms

• the engine may stall

• Output Fall



P0201 (flashing code 271) open nozzle on the 1st drive system

The main fault symptoms

• severe engine vibration

• idling unstable

• Output power down

• channeling gas engine failure



P0202 (flashing code 272) open the nozzle on the 2nd drive system

The main fault symptoms

• severe engine vibration

• idling unstable

• Output power down

• blown engine failure



P0203 (flashing code 273) open nozzle on the 3rd drive system

The main fault symptoms

• severe engine vibration

• idling unstable

• Output power down

• channeling gas engine failure

P0202 (flashing code 272) open the nozzle on the 2nd drive system

The main fault symptoms

• severe engine vibration

• idling unstable

• Output power down

• blown engine failure



P0203 (flashing code 273) open nozzle on the 3rd drive system

The main fault symptoms

• severe engine vibration

• idling unstable

• Output power down

• channeling gas engine failure



P0204 (flashing code 274) open the nozzle on the 4th drive system

The main fault symptoms

• severe engine vibration

• idling unstable

• Output power down

• blown engine failure



P0205 (flashing code 275) open the nozzle on the 5th drive system

The main fault symptoms

• severe engine vibration

• idling unstable

• Output power down

• Engine Knock abnormal



P0206 (flashing code 276) open the nozzle on the 6th drive system

The main fault symptoms

• severe engine vibration

• idling unstable

• Output power down

• Engine Knock abnormal



P0219 (flashing code 543) speeding

The main fault symptoms

Output Fall



P0237 (flashing code 32) boost pressure sensor failure (low voltage fault, open circuit)

The main fault symptoms

Smoky.



P0238 (flashing code 32) boost pressure sensor failure (high voltage failure, power short circuit, grounding open)



P0335 (flashing code 15) crankshaft sensor fault (no signal)

The main fault symptoms

• Output Fall

• row of white smoke

• Engine vibration may be severe

• the engine may stall (when the camshaft position sensor is normal, can

To re-start



P0336 (flashing code 15) crankshaft sensor fault (signal failure)

The main fault symptoms

• Output Fall

• row of white smoke

• Engine vibration may be severe

• the engine may stall (when the camshaft position sensor is normal, can

To re-starting
