Dodge W150 W250 W350 Truck 1993 Service Repair Manual

Dodge Truck

The information contained in this service manual has been prepared for the professional automotive technician involved in daily repair operations. This manual does not cover theory of operation, which is addressed in sendee training material. Information describing the operation and use of standard and optional equipment is included in the Owner’s Manual provided with the vehicle.

Information in this manual is divided into groups. These groups contain general information, diagnosis, testing, adjustments, removal, installation, disassembly, and assembly procedures for the components.

The Component and System Index of this manual identifies the correct group for the component or system to be serviced. In addition, a Service Manual Comment form is included at the rear of this manual. Use the form to provide Chrysler Corporation with your comments and suggestions.

To assist in locating a group title page, use the Group Tab Locator on the following page. The solid bar after the group title is aligned to a solid tab on the first page of each group. The first page of the group has a contents section that lists major topics within the group.

Tightening torques are provided as a specific value throughout this manual. This value represents the midpoint, of the acceptable engineering torque range for a given fastener application. These torque values are intended for use in service assembly and installation procedures using the correct OEM fasteners. When replacing fasteners, always use the same type (part number) fastener as removed.

This manual covers all 1993 Dodge Pickup Truck models including D & W 150 250 350, half ton, three quarter ton, one ton, S, Sport Utility, Conventional Cab, Club Cab & Ramcharger. Includes 2 wheel drive and 4 wheel drive.

CONTENTS:

  • Lubrication and Maintenance
  • Front Suspension and Axle
  • Rear Suspension and Axles
  • Brakes
  • Clutch
  • Cooling System
  • Electrical
  • Engines
  • Exhaust System and Intake Manifold
  • Frame and Bumpers
  • Fuel System
  • Propeller Shafts
  • Steering
  • Transmission and Transfer Case
  • Wheels and Tires
  • Body Components
  • Heating and Air Conditioning
  • Emission Control Systems
  • Component and System Index

Language: English
File: PDF
Pages: 1502
