CHRYSLER 300, 300C, 300 TOURING SEDANS AND DODGE MAGNUM 2005 BODY REPAIR MANUAL

CHRYSLER 300, 300C, 300 TOURING SEDANS AND DODGE MAGNUM 2005 BODY REPAIR MANUAL PDF free online

This manual has been prepared for use by all body technicians involved in the repair of the 300, 300C, 300 Touring & Dodge Magnum

This manual shows:

  • Typical unibody panels contained in these vehicles
  • The types of welds for the panel
  • The weld locations for these panels
  • Proper sealer types and correct locations

DaimlerChrysler Motors Corporation reserves the right to make improvements in design or to change specifications to these vehicles without incurring any obligation upon itself.

All test and repair procedures on components or assemblies in non-automotive applications should be repaired in accordance with instructions supplied by the manufacturer of the total product.

Proper service and repair is important to the safe, reliable operation of all motor vehicles. The service produces recommended and described in this publication were developed for professional service personnel, and are effective methods for performing vehicle repair. Following these procedures will help ensure efficient economical vehicle performance and service reliability. Some service procedures require the use of special tools designed for specific procedures. These special tools should be used as recommended throughout this publication.

Special attention should be exercised when working with spring-or tension-loaded fasteners and devices such as E-Clips, Circlips, Snap rings, etc., since careless removal may cause personal injury. Always wear safety goggles when working on vehicles or vehicle components.

It is important to note that this publication contains various Cautions and Warnings. These should be read carefully in order to minimize risk of personal injury or the possibility that improper service methods may damage the vehicle or render it unsafe. It is important to note that these Cautions and Warnings cover only the situations and procedures DaimlerChrysler Corporation has encountered and recommended.

CONTENTS

  • Body Construction Characteristics
  • History of Collision Repair
  • Body Code Plate Information
  • Vehicle Identification Number Information
  • Corrosion Protection
  • Welded Panel Replacement
  • Sealer Locations
  • Sound Deadner Locations
  • Structural Adhesive Locations
  • Frame/Body Dimensions
  • Additional Support/Information

Language: English
Format: PDF
Pages: 405
