The Pioduct Description Manual depicts the design intent required for final assembly of the vehicle. It is to be considered as an authoritative source of information and placement of ttie various component parts of tlie vehicle. The views shown may be accompanied by instructions and/or procedures. However, the method of assembly and installation sequence is not determined by Product Engineering unless the instructions are requested by the tesponsible processing department in conjunction with Product Engineering.

The manual is divided up pel the basic Uniform Parts Class! I’icatinn (UPC) Sections (0 thru 15), with a content sheet at the beginning of each section. Options have been integrated into the respective sub-sections of the major UPC sections to which the parts and assemblies are assigned at point of release.

CONTENTS

  • Introduction to Product Description Manual (PDM)
  • Chevrolet Motor Division
  • 1981 All Passengers Cars
  • 1981 All Vehicles
  • 1981 All Pass (exc “y”)
  • 1981 Chevrolet “F” 14020867
  • Oldsmobile Division
  • Pontiac Motor Division
  • 1- Body
  • 2- Frame
  • 3- Front Suspension
  • 4- Rear Axle & Rear Suspension
  • 5- Brakes
  • 6L- Engine Heat Control and Manifolds
  • 6Q- Engine/ Transmission Mounting
  • Attaching Bolt/ Screw Torque Sequence

Language: English
Format: PDF
Pages: 354
