BMW E36/5 318ti 1997 Electrical Troubleshooting Manual
This comprehensive Electrical Troubleshooting Manual provides detailed guidance for diagnosing and repairing electrical faults in the BMW 3-Series E36/5 (318ti) models produced between September 1996 and August 1997.
Key Features and Benefits:
- Step-by-step troubleshooting procedures guide you through the diagnostic process, identifying potential causes and solutions.
- Detailed electrical schematics and diagrams visually represent the electrical systems, aiding in component identification and circuit tracing.
- Important specifications and measurements ensure accurate and efficient repairs.
- Tailored specifically for the 1996-1997 BMW 3-Series E36/5 (318ti), catering to its unique electrical system configuration.
- Empowers users to perform electrical repairs themselves, saving time and money while gaining a deeper understanding of their vehicle.
Technical Specifications and Details:
Electrical System:
- 12-volt negative ground system
- Battery capacity: 60 Ah
- Alternator output: 90 amps
Major Electrical Components:
- Engine control module (ECM)
- Ignition coil
- Starter motor
- Voltage regulator
- Headlight switch
- Turn signal switch
- Wiper switch
Maintenance and Repair Information:
Battery Replacement:
- Recommended battery: BMW-approved 12-volt battery with 60 Ah capacity
- Battery location: Under the hood, on the passenger side
Fuse and Relay Replacement:
- Fuse and relay panel locations:
- Under the hood, next to the battery
- Inside the cabin, under the dashboard
- Fuse and relay identification: Refer to the electrical troubleshooting manual for specific locations and ratings
Electrical Troubleshooting:
- Use a multimeter to measure voltage, current, and resistance
- Inspect wiring harness for damage or loose connections
- Consult the electrical troubleshooting manual for circuit testing procedures
Common Electrical Problems and Solutions:
Battery Drain:
- Symptoms: Difficulty starting the vehicle, dim headlights
- Solution: Check for parasitic drains using a multimeter, inspect battery terminals for corrosion
Electrical Shorts:
- Symptoms: Blown fuses, intermittent electrical failures
- Solution: Inspect wiring harness for damage, repair or replace damaged wires
Ground Faults:
- Symptoms: Electrical components not functioning properly
- Solution: Check ground connections for tightness and corrosion, clean or repair as needed
This comprehensive BMW SERIES 3 – E36/5 (318ti) Electrical Troubleshooting Manual (P/N 01 00 1 470 353) is an indispensable resource for owners and technicians alike. Its detailed troubleshooting procedures, electrical schematics, and technical specifications empower you to diagnose and repair electrical faults with confidence and precision.
CONTENTS
- Introduction
- Symbols
- Power Distribution Chart
- Fuse Chart
- Power Distribution
- Fuse Details
- Ground Distribution
- Data Link
- Engine Control System (DME M5.2.4-Cvlinder M44)
- Charging System
- Start
- Electronic Transmission Control (EGS A4S 31 OR)
- Supplemental Restraint System (AIR BAG)
- Slip Control (ABS)
- Slip Control (ABS/ASC)
- Power Mirrors
- ZKE Central Locking (ZV)
- Power Windows (FH)
- Heated Seats
- Power Sunroof (SHD)
- Electric Folding Sunroof
- Central Body Electronics (ZKE IV)
- Horn
- Drive-Away Protection (EWS II)
- Wiper/Washer Module (WWM)
- Windshield Washer Jet Heaters
- Instrument cluster
- Clock
- Light Switch Details
- Headlights/Fog Lights
- Turn/Hazard Lights
- Park/Tail/Underhood Lights
- License Plate/Luggage Compartment Lights
- Back Up Lights
- Brake Lights
- Interior Lights
- Interior Accesories
- Crash Control Module
- Heating Control (HS)
- Rear Window Defogger
- Intergrated Heating- and Climate Control
- Radio/Stereo
- Radio/Hifi
- Cellular Telephone (Provisions)
- Cruise control (Tempomat)
- Anti-Theft System (Alpine)
- On-Board Computer (BC-Low)
- Component Location Chart
- Component Location Views
- Splice Location Views
- Connector Views
Language: English
Format: PDF
Pages: 275
