BMW 525i 535i 1989 Electrical Troubleshooting Manual

This comprehensive Electrical Troubleshooting Manual provides detailed guidance for diagnosing and repairing electrical faults in 1989 BMW 525i and 535i (E34) models produced from June 1988 to February 1989.

Key Features and Benefits:

  • Step-by-step troubleshooting procedures guide you through the diagnostic process, identifying potential causes and solutions.
  • Detailed electrical schematics and diagrams visually represent the electrical systems, aiding in component identification and circuit tracing.
  • Important specifications and measurements ensure accurate and efficient repairs.
  • Tailored specifically for the 1989 BMW 525i/535i (E34), catering to its unique electrical system configuration.
  • Empowers users to perform electrical repairs themselves, saving time and money while gaining a deeper understanding of their vehicle.

Technical Specifications and Details:

Electrical System:

  • 12-volt negative ground system
  • Battery capacity: 60 Ah
  • Alternator output: 90 amps

Major Electrical Components:

  • Engine control module (ECM)
  • Ignition coil
  • Starter motor
  • Voltage regulator
  • Headlight switch
  • Turn signal switch
  • Wiper switch

Maintenance and Repair Information:

Battery Replacement:

  • Recommended battery: BMW-approved 12-volt battery with 60 Ah capacity
  • Battery location: Under the hood, on the passenger side

Fuse and Relay Replacement:

  • Fuse and relay panel locations:
    • Under the hood, next to the battery
    • Inside the cabin, under the dashboard
  • Fuse and relay identification: Refer to the electrical troubleshooting manual for specific locations and ratings

Electrical Troubleshooting:

  • Use a multimeter to measure voltage, current, and resistance
  • Inspect wiring harness for damage or loose connections
  • Consult the electrical troubleshooting manual for circuit testing procedures

Common Electrical Problems and Solutions:

Battery Drain:

  • Symptoms: Difficulty starting the vehicle, dim headlights
  • Solution: Check for parasitic drains using a multimeter, inspect battery terminals for corrosion

Electrical Shorts:

  • Symptoms: Blown fuses, intermittent electrical failures
  • Solution: Inspect wiring harness for damage, repair or replace damaged wires

Ground Faults:

  • Symptoms: Electrical components not functioning properly
  • Solution: Check ground connections for tightness and corrosion, clean or repair as needed

This comprehensive 1989 BMW 525i/535i (E34) Electrical Troubleshooting Manual is an indispensable resource for owners and technicians alike. Its detailed troubleshooting procedures, electrical schematics, and technical specifications empower you to diagnose and repair electrical faults with confidence and precision.

CONTENTS

  • Index
  • Introduction
  • Systematic Troubleshooting
  • Symbols
  • Power Distribution Charts
  • Fuse Charts
  • Power Distribution
  • Fuse Details0
  • Ground Distribution
  • Diagnostic Link
  • Injection Electronics (DME 1.3)
  • Charging System
  • Start
  • E- Box Fan
  • Electronic Transmission Control (AEGS)
  • Supplemental Restraint System (Air Bag)
  • Power Assist Steering (Servotronic)
  • Power Assist Steering (Servotronic)
  • Antilock Brake System (ABS)
  • Power Mirrors
  • ZKE Door Lock Heating (TSH)
  • ZKE Central Locking (ZV)
  • ZKE Power Windows (FH)
  • Power Seats
  • ZKE Sunroof (SHD)
  • Central Body Electronics (ZKE)
  • Horn
  • ZKE Windshield Wiper Control (SWS)
  • ZKE Windshield Wiper Pressure Control (ADV)
  • Windshield Washer Jet Heaters
  • Instrument Cluster/ Check Control (K/ CC)
  • Light Switch Details
  • Lamp Monitor (LKM)
  • Headlights/ Fog Lights
  • Headlights/ Fog Lights
  • Turn/ Hazard Lights
  • Park/ Tail/ Underhood Lights
  • License/ Trunk Lights
  • Back Up Lights
  • Brake Lights
  • ZKE Interior Lights (IB)
  • Glove Box Light/ Cigar Lighter/ Charging Plug
  • Integrated Climate Regulation (IHKR)
  • Auxiliary Fan
  • Radio/ CD Player (Provisions)
  • Cellular Telephone (Provisions)
  • Cruise Control (Tempomat)
  • On- Board Computer (BCIV)
  • Component Location Chart
  • Component Location Views
  • Component Location Views
  • Splice Location Views
  • Connector Views

Language: English
Format: PDF
Pages: 334
