BMW 325iX 1988 Electrical Troubleshooting Manual

1988 BMW 325iX  electrical wiring diagrams, pin assignments, component locations, connector views, functional descriptions, measuring devices, desired values, help texts, functional tests.

The purpose of this manual is to show electrical schematics in a manner that makes electrical troubleshooting easier. Electrical components which work together are shown together on one schematic. The Wiper-Washer schematic, for example, shows all of the electrical components in one diagram. At the top of the page is the fuse (positive) that powers the circuit The flow of current is shown through all wires, connectors, switches, and motors to ground (negative) at the bottom of the page.

Within the schematic, all switches and sensors are shown “at rest,” as though the Ignition Switch were off. For identification, component names are underlined and placed next to or above each component. Notes are included, describing how switches and other components work.

The power distribution schematic shows the current feed through all the connections from the Battery and Alternator to each fuse and the Ignition and Light Switches. If the Power Distribution schematic is combined with any other circuit schematic, a complete picture is made of how that circuit works. The Ground Distribution schematics show how several circuits are connected to common grounds.

All wiring between components is shown exactly as it exists in the vehicle; however, the wiring is not drawn to scale. To aid in understanding electrical operation, wiring inside complicated components has been simplified. The “Solid State” label designates electronic components.

CONTENTS

  • Index
  • How To Use This Manual
  • Symbols
  • Wire Size Conversion Chart
  • Systematic Troubleshooting
  • Connector Views
  • Power Distribution Box
  • Fuse Data
  • Component Location Chart
  • Component Location Views
  • Splice Location Views

Language: English
Format: PDF
Pages: 130

BMW 325iX 1988 Electrical Troubleshooting Manual
